Steel Gear Reversible permanent magnet 37mm dia 3530 12v 70rpm dc geared reduction motor CE ROHS

Ask Lasest Price
Brand Name :	TYHE
Model Number :	TJZ37FK
Certification :	CE/ROHS/ISO9001
Price :	Negotiation
Payment Terms :	T/T, Western Union
Supply Ability :	100000pcs per month
Delivery Time :	15 working days after payment

Add to Cart

Product Details
Company Profile

Steel Gear Reversible permanent magnet 37mm dia 3530 12v 70rpm dc geared reduction motor CE ROHS

Products Description

Steel Gear Reversible Permanent Magnet 37mm Dia 3530 12v 70rpm Dc Geared Reduction Motor CE ROHS

2D drawing

Model	End cover dimensions	Motor type	Regular Shaft	Weight
TJZ37FK	φ37mm	30-C	6mm-D cut	190g


Specifications

DC Motor Technical Data
Model	Rated Voltage(V)	No-Load Parameters		Rated Parameters					Stall Parameters
		Speed	Current	Speed	Current	Torque	Output	eff	Torque	Current
		rpm	mA	rpm	A	mN.m	W	%	mN.m	A
ZY3530	12	5500	60	4400	0.23	3.81	1.76	62.69	11.43	1.72
ZY3530	12	6500	65	5200	0.31	4.18	2.28	61.18	12.54	2.00
ZY3530	24	3500	14	2800	0.06	3.17	0.93	62.63	9.51	0.49
ZY3530	24	5200	22	4160	0.11	4.01	1.75	63.47	12.03	0.98
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters			12V-5500RPM Input				12V-6500RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
22.5	81	4.6	956.5	1.42	14.20	42.59	1130.4	1.84	15.57	46.72
22.5	81	5.9	745.8	1.42	18.21	54.62	881.4	1.84	19.98	59.93
22.5	81	6.9	637.7	1.42	21.29	63.88	753.6	1.84	23.36	70.09
22.5	73	8.4	523.8	1.28	23.36	70.09	619.0	1.66	25.63	76.90
22.5	73	10.6	415.1	1.28	29.48	88.45	490.6	1.66	32.34	97.03
22.5	73	13.5	325.9	1.28	37.55	112.64	385.2	1.66	41.19	123.58
22.5	73	16.0	275.0	1.28	44.50	133.50	325.0	1.66	48.82	146.47
24.5	65.6	19.3	228.0	1.15	48.24	144.71	269.4	1.49	52.92	158.77
24.5	65.6	24.4	180.3	1.15	60.98	182.95	213.1	1.49	66.91	200.72
24.5	65.6	31.6	139.2	1.15	78.98	236.94	164.6	1.49	86.65	259.95
24.5	65.6	37.0	118.9	1.15	92.48	277.43	140.5	1.49	101.46	304.37
26.5	59	45.0	97.8	1.04	101.16	303.47	115.6	1.34	110.98	332.94
26.5	59	57.0	77.2	1.04	128.13	384.39	91.2	1.34	140.57	421.72
26.5	59	73.6	59.8	1.04	165.45	496.34	70.7	1.34	181.51	544.54
26.5	59	86.0	51.2	1.04	193.32	579.96	60.5	1.34	212.09	636.28
26.5	59	95.0	46.3	1.04	213.55	640.65	54.7	1.34	234.29	702.87
29.5	53	105.0	41.9	0.93	212.03	636.08	49.5	1.21	232.62	697.85
29.5	53	133.0	33.1	0.93	268.57	805.70	39.1	1.21	294.65	883.94
29.5	53	172.0	25.6	0.93	347.32	1041.96	30.2	1.21	381.05	1143.15
29.5	53	201.0	21.9	0.93	405.88	1217.64	25.9	1.21	445.30	1335.89
29.5	53	221.0	19.9	0.93	446.27	1338.80	23.5	1.21	489.60	1468.81
29.5	53	244.0	18.0	0.93	492.71	1478.13	21.3	1.21	540.56	1621.67
32.5	47.8	245.0	18.0	0.84	446.19	1338.57	21.2	1.09	489.52	1468.56
32.5	47.8	310.0	14.2	0.84	564.57	1693.70	16.8	1.09	619.39	1858.18
32.5	47.8	401.0	11.0	0.84	730.29	2190.88	13.0	1.09	801.21	2403.64
32.5	47.8	469.0	9.4	0.84	854.13	2500.00	11.1	1.09	937.08	2500.00
32.5	47.8	516.0	8.5	0.84	939.73	2500.00	10.1	1.09	1030.99	2500.00
32.5	47.8	569.0	7.7	0.84	1036.25	2500.00	9.1	1.09	1136.88	2500.00
32.5	47.8	627.0	7.0	0.84	1141.88	2500.00	8.3	1.09	1252.77	2500.00
32.5	43	1093.0	4.0	0.75	1790.66	2500.00	4.8	0.98	1964.56	2500.00
32.5	43	1205.0	3.7	0.75	1974.15	2500.00	4.3	0.98	2165.87	2500.00
32.5	43	1328.0	3.3	0.75	2175.66	2500.00	3.9	0.98	2386.95	2500.00
32.5	43	1463.0	3.0	0.75	2396.83	2500.00	3.6	0.98	2500.00	2500.00
32.5	43	1613.0	2.7	0.75	2500.00	2500.00	3.2	0.98	2500.00	2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters			24V-3500RPM Input				24V-5200RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
22.5	81	4.6	608.7	0.75	11.81	35.43	904.3	1.41	14.94	44.82
22.5	81	5.9	474.6	0.75	15.15	45.45	705.1	1.41	19.16	57.49
22.5	81	6.9	405.8	0.75	17.72	53.15	602.9	1.41	22.41	67.24
22.5	73	8.4	333.3	0.68	19.44	58.32	495.2	1.28	24.59	73.77
22.5	73	10.6	264.2	0.68	24.53	73.59	392.5	1.28	31.03	93.09
22.5	73	13.5	207.4	0.68	31.24	93.72	308.1	1.28	39.52	118.56
22.5	73	16.0	175.0	0.68	37.03	111.08	260.0	1.28	46.84	140.51
24.5	65.6	19.3	145.1	0.61	40.13	120.40	215.5	1.15	50.77	152.31
24.5	65.6	24.4	114.8	0.61	50.74	152.22	170.5	1.15	64.19	192.56
24.5	65.6	31.6	88.6	0.61	65.71	197.14	131.6	1.15	83.13	249.38
24.5	65.6	37.0	75.7	0.61	76.94	230.83	112.4	1.15	97.33	291.99
26.5	59	45.0	62.2	0.55	84.16	252.49	92.4	1.03	106.47	319.40
26.5	59	57.0	49.1	0.55	106.61	319.82	73.0	1.03	134.86	404.57
26.5	59	73.6	38.0	0.55	137.65	412.96	56.5	1.03	174.13	522.39
26.5	59	86.0	32.6	0.55	160.85	482.54	48.4	1.03	203.47	610.40
26.5	59	95.0	29.5	0.55	177.68	533.04	43.8	1.03	224.76	674.28
29.5	53	105.0	26.7	0.49	176.41	529.23	39.6	0.93	223.16	669.47
29.5	53	133.0	21.1	0.49	223.45	670.36	31.3	0.93	282.66	847.99
29.5	53	172.0	16.3	0.49	288.98	866.93	24.2	0.93	365.55	1096.65
29.5	53	201.0	13.9	0.49	337.70	1013.10	20.7	0.93	427.19	1281.56
29.5	53	221.0	12.7	0.49	371.30	1113.91	18.8	0.93	469.69	1409.07
29.5	53	244.0	11.5	0.49	409.94	1229.83	17.0	0.93	518.57	1555.72
32.5	47.8	245.0	11.4	0.44	371.24	1113.72	17.0	0.83	469.61	1408.83
32.5	47.8	310.0	9.0	0.44	469.73	1409.19	13.4	0.83	594.20	1782.61
32.5	47.8	401.0	7.0	0.44	607.62	1822.86	10.4	0.83	768.63	2305.89
32.5	47.8	469.0	6.0	0.44	710.66	2131.97	8.9	0.83	898.97	2500.00
32.5	47.8	516.0	5.4	0.44	781.87	2345.62	8.1	0.83	989.06	2500.00
32.5	47.8	569.0	4.9	0.44	862.18	2500.00	7.3	0.83	1090.65	2500.00
32.5	47.8	627.0	4.5	0.44	950.07	2500.00	6.6	0.83	1201.82	2500.00
32.5	43	1093.0	2.6	0.40	1489.87	2500.00	3.8	0.75	1884.66	2500.00
32.5	43	1205.0	2.3	0.40	1642.54	2500.00	3.5	0.75	2077.78	2500.00
32.5	43	1328.0	2.1	0.40	1810.20	2500.00	3.1	0.75	2289.87	2500.00
32.5	43	1463.0	1.9	0.40	1994.22	2500.00	2.8	0.75	2500.00	2500.00
32.5	43	1613.0	1.7	0.40	2198.68	2500.00	2.6	0.75	2500.00	2500.00

Please let us know your requirements and we will provide you with transmission solutions.
