6mm Rotation Shaft Jgb37 Micro DC Gear Motor 550rpm High Torque 2nm 1.5nm

Product Categories

Wenzhou Tyhe Motor Co., Ltd.

Contact Now

6mm Rotation Shaft Jgb37 Micro DC Gear Motor 550rpm High Torque 2nm 1.5nm

Ask Lasest Price
Brand Name :	TYHE
Model Number :	TJP37RG
Certification :	CE/ROHS/ISO9001
Price :	Negotiation
Payment Terms :	T/T, Western Union
Supply Ability :	100000pcs per month
Delivery Time :	15 working days after payment

Add to Cart

Product Details
Company Profile

6mm Rotation Shaft Jgb37 Micro DC Gear Motor 550rpm High Torque 2nm 1.5nm

Products Description

6mm Rotation Shaft Jgb37 550rpm 12v 12 Volt 24v High Torque 2nm 1.5nm 30 Rpm Micro Dc Gear Motor

2D drawing


Specifications

DC Motor Technical Data
Model	Rated Voltage(V)	No-Load Parameters		Rated Parameters					Stall Parameters
		Speed	Current	Speed	Current	Torque	Output	eff	Torque	Current
		rpm	mA	rpm	A	mN.m	W	%	mN.m	A
RS555	12	5000	240	4000	0.93	16.80	7.04	63.28	50.40	6.80
RS555	12	6500	310	5200	1.42	19.50	10.62	62.24	58.50	11.48
RS555	24	5000	150	4000	0.49	17.50	7.33	62.12	52.50	3.20
RS555	24	7600	220	6080	1.01	23.20	14.77	61.24	69.60	8.10
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters			12V-5000RPM Input				12V-6500RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
22.5	81	6.5	615.4	5.70	88.45	265.36	800.0	8.60	102.67	308.00
22.5	73	9.3	430.1	5.14	114.06	342.17	559.1	7.75	132.39	397.16
22.5	73	11.8	339.0	5.14	144.72	434.15	440.7	7.75	167.97	503.92
22.5	73	14.2	281.7	5.14	174.15	522.45	366.2	7.75	202.14	606.41
22.5	73	17.4	229.9	5.14	213.39	640.18	298.9	7.75	247.69	743.07
24.5	65.6	21.8	183.5	4.62	240.25	720.76	238.5	6.97	278.87	836.60
24.5	65.6	27.5	145.5	4.62	303.07	909.22	189.1	6.97	351.78	1055.34
24.5	65.6	36.6	109.3	4.62	403.36	1210.08	142.1	6.97	468.19	1404.56
24.5	65.6	40.4	99.0	4.62	445.24	1335.72	128.7	6.97	516.80	1550.39
26.5	59	58.1	68.8	4.15	575.89	1727.66	89.5	6.26	668.44	2005.32
26.5	59	73.4	54.5	4.15	727.54	2182.62	70.8	6.26	844.47	2500.00
26.5	59	83	48.2	4.15	822.70	2468.09	62.7	6.26	954.92	2500.00
26.5	59	89	44.9	4.15	882.17	2500.00	58.4	6.26	1023.95	2500.00
26.5	59	95	42.1	4.15	941.64	2500.00	54.7	6.26	1092.98	2500.00
26.5	59	103	38.8	4.15	1020.94	2500.00	50.5	6.26	1185.02	2500.00
29.5	53	119	33.6	3.73	1059.58	2500.00	43.7	5.63	1229.87	2500.00
29.5	53	136	29.4	3.73	1210.94	2500.00	38.2	5.63	1405.56	2500.00
29.5	53	171	23.4	3.73	1522.58	2500.00	30.4	5.63	1767.29	2500.00
29.5	53	194	20.6	3.73	1727.38	2500.00	26.8	5.63	2004.99	2500.00
29.5	53	207	19.3	3.73	1843.13	2500.00	25.1	5.63	2139.35	2500.00
29.5	53	221	18.1	3.73	1967.78	2500.00	23.5	5.63	2284.04	2500.00
29.5	53	242	16.5	3.73	2154.77	2500.00	21.5	5.63	2500.00	2500.00
29.5	53	277	14.4	3.73	2466.41	2500.00	18.8	5.63	2500.00	2500.00
29.5	53	305	13.1	3.73	2500.00	2500.00	17.0	5.63	2500.00	2500.00
32.5	47.8	350	11.4	3.36	2500.00	2500.00	14.9	5.08	2500.00	2500.00
32.5	47.8	422	9.5	3.36	2500.00	2500.00	12.3	5.08	2500.00	2500.00
32.5	47.8	465	8.6	3.36	2500.00	2500.00	11.2	5.08	2500.00	2500.00
32.5	47.8	513	7.8	3.36	2500.00	2500.00	10.1	5.08	2500.00	2500.00
32.5	47.8	532	7.5	3.36	2500.00	2500.00	9.8	5.08	2500.00	2500.00
32.5	47.8	586	6.8	3.36	2500.00	2500.00	8.9	5.08	2500.00	2500.00
32.5	47.8	712	5.6	3.36	2500.00	2500.00	7.3	5.08	2500.00	2500.00
32.5	47.8	784	5.1	3.36	2500.00	2500.00	6.6	5.08	2500.00	2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters			24V-5000RPM Input				24V-7600RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
22.5	81	6.5	615.4	5.94	92.14	276.41	935.4	11.96	122.15	366.44
22.5	73	9.3	430.1	5.35	118.81	356.42	653.8	10.78	157.50	472.51
22.5	73	11.8	339.0	5.35	150.75	452.24	515.3	10.78	199.84	599.53
22.5	73	14.2	281.7	5.35	181.41	544.22	428.2	10.78	240.49	721.47
22.5	73	17.4	229.9	5.35	222.29	666.86	349.4	10.78	294.69	884.06
24.5	65.6	21.8	183.5	4.81	250.26	750.79	278.9	9.69	331.78	995.34
24.5	65.6	27.5	145.5	4.81	315.70	947.10	221.1	9.69	418.53	1255.58
24.5	65.6	36.6	109.3	4.81	420.17	1260.50	166.1	9.69	557.02	1671.07
24.5	65.6	40.4	99.0	4.81	463.79	1391.38	150.5	9.69	614.86	1844.57
26.5	59	58.1	68.8	4.32	599.88	1799.65	104.6	8.71	795.27	2385.82
26.5	59	73.4	54.5	4.32	757.86	2273.57	82.8	8.71	1004.70	2500.00
26.5	59	83	48.2	4.32	856.98	2570.93	73.3	8.71	1136.10	2500.00
26.5	59	89	44.9	4.32	918.93	2756.78	68.3	8.71	1218.23	2500.00
26.5	59	95	42.1	4.32	980.88	2942.63	64.0	8.71	1300.36	2500.00
26.5	59	103	38.8	4.32	1063.48	3190.43	59.0	8.71	1409.86	2500.00
29.5	53	119	33.6	3.88	1103.73	2500.00	51.1	7.83	1463.22	2500.00
29.5	53	136	29.4	3.88	1261.40	2500.00	44.7	7.83	1672.26	2500.00
29.5	53	171	23.4	3.88	1586.03	2500.00	35.6	7.83	2102.62	2500.00
29.5	53	194	20.6	3.88	1799.35	2500.00	31.3	7.83	2385.42	2500.00
29.5	53	207	19.3	3.88	1919.93	2500.00	29.4	7.83	2500.00	2500.00
29.5	53	221	18.1	3.88	2049.78	2500.00	27.5	7.83	2500.00	2500.00
29.5	53	242	16.5	3.88	2244.55	2500.00	25.1	7.83	2500.00	2500.00
29.5	53	277	14.4	3.88	2500.00	2500.00	21.9	7.83	2500.00	2500.00
29.5	53	305	13.1	3.88	2500.00	2500.00	19.9	7.83	2500.00	2500.00
32.5	47.8	350	11.4	3.50	2500.00	2500.00	17.4	7.06	2500.00	2500.00
32.5	47.8	422	9.5	3.50	2500.00	2500.00	14.4	7.06	2500.00	2500.00
32.5	47.8	465	8.6	3.50	2500.00	2500.00	13.1	7.06	2500.00	2500.00
32.5	47.8	513	7.8	3.50	2500.00	2500.00	11.9	7.06	2500.00	2500.00
32.5	47.8	532	7.5	3.50	2500.00	2500.00	11.4	7.06	2500.00	2500.00
32.5	47.8	586	6.8	3.50	2500.00	2500.00	10.4	7.06	2500.00	2500.00
32.5	47.8	712	5.6	3.50	2500.00	2500.00	8.5	7.06	2500.00	2500.00
32.5	47.8	784	5.1	3.50	2500.00	2500.00	7.8	7.06	2500.00	2500.00

Please let us know your requirements and we will provide you with transmission solutions.
